- 3 -
Table of Contents
Z590 GAMING X AX/Z590 GAMING X Motherboard Layout ..........................................4
Chapter 1 Hardware Installation .....................................................................................5
1-1 Installation Precautions .................................................................................... 5
1-2 ProductSpecications ...................................................................................... 6
1-3 Installing the CPU .......................................................................................... 10
1-4 Installing the Memory ..................................................................................... 10
1-5 Installing an Expansion Card ......................................................................... 11
1-6 Back Panel Connectors .................................................................................. 11
1-7 Internal Connectors ........................................................................................ 13
Chapter 2 BIOS Setup ..................................................................................................24
2-1 Startup Screen ............................................................................................... 24
2-2 The Main Menu .............................................................................................. 25
2-3 Smart Fan 6 .................................................................................................. 26
2-4 Favorites (F11) ............................................................................................... 27
2-5 Tweaker .......................................................................................................... 28
2-6 Settings .......................................................................................................... 34
2-7 System Info. ................................................................................................... 39
2-8 Boot ................................................................................................................ 40
2-9 Save & Exit ..................................................................................................... 43
Chapter 3 Appendix ......................................................................................................44
3-1 ConguringaRAIDSet .................................................................................. 44
3-2 Installing Intel
®
Optane
™
Memory and Storage Management ........................ 45
3-3 DriversInstallation .......................................................................................... 47
RegulatoryNotices .................................................................................................... 48
Contact Us ................................................................................................................ 52
