*) Optional accessories / Option depending on model

Original instruction

SLO

RUS

EST

Makita VC 4210 M

Quick reference guide

Operating elements

1 Hose hook

2 Handle

3 Accessory positions

4 Suction power control

5 Switch

6 Inlet cap

7 Castor

8 Container

9 Inlet fitting

10 Latch

11 Appliance socket

12 LED indicator

13 Hose diameter setting

The pictorial quick reference guide

The pictorial quick reference guide is designed for

helping you when starting up, operating and storing

the unit. The guide are subdivided into 4 sections,

which are represented by symbols:

Before starting

DO READ OPERATING INSTRUCTIONS BEFORE

USE!

A1 - Unpack accessories

A2 - Filter bag installation

A3 - Disposal bag installation

A4 - Hose insert & operations

A5 - Accessories placement

A6 - Adaptor plate installation

A7 - Trolley handle installation

Control/Operation

B1 - Flow rate warning

B2 - AutoClean filter cleaning system

B3 - Cable and hose storage

Connecting electrical appliances

C1 - Power tool adaption

Maintenance

D1 - Filter bag replacement

D2 - Disposal bag replacement

D3 - Filter replacement

D4 - Motor cooling air diffuser cleaning

D5 - Gaskets and floater cleaning

Contents

1 Safety instructions .................................... 11

1.1 Symbols used to mark instructions ..............11

1.2 Instructions for use .......................................11

1.3 Purpose and intended use ...........................11

1.4 Electrical connection ....................................11

1.5 Extension lead ............................................. 12

1.6 Guarantee ................................................... 12

1.7 Important warnings ...................................... 12

2 Risks 12

2.1 Electrical components ................................. 12

2.2 Hazardous dust ........................................... 13

2.3 Spare parts and accessories ....................... 13

2.4 In explosive or inflammable atmosphere ..... 13

3 Control / Operation .................................... 13

3.1 Starting and operating of the machine ........ 13

3.2 Auto-On/Off socket outlet for power tools ... 14

3.3 AutoClean ................................................... 14

3.4 Flow rate warning ........................................ 14

3.5 Antistatic connection

................................. 14

3.6 Cooling air filter ........................................... 14

3.7 Wet pick-up ................................................. 15

3.8 Dry pick-up .................................................. 15

4 After using the machine ........................... 15

4.1 After use ...................................................... 15

4.2 Transport ..................................................... 15

4.3 Storage ........................................................ 15

4.4 Accessory and tool storage ......................... 16

4.5 Recycling the machine ................................ 16

5 Maintenance............................................... 16

5.1 Regular servicing and inspection ................ 16

5.2 Maintenance ................................................ 16

6 Further information ................................... 17

6.1 EU Declaration of conformity ...................... 17

6.2 Specifications .............................................. 18
