*) Optional accessories / Option depending on model

Original instruction

SLO

RUS

EST

Makita VC 4210 M

ø21 ø21

ø27 ø27

ø32 ø32

ø36 ø36

ø38 ø38

3.2 Auto-On/Off socket outlet for power tools

CAUTION

Appliance socket.

The appliance socket is designed for electrical

auxiliary equipment; see technical data for refer-

ence.

1. Prior to plugging in an appliance, always switch

off the machine and the appliance that is to be

connected.

2. Read the operating instructions to the appliance

to be connected and observe the safety notes

contained in these.

An appliance socket with earthing contact is inte-

grated in the machine. An external power tool can

be connected there. The socket features permanent

power on, when the electrical switch is in position

, i.e. the machine can be used as an extension

cord.

In position AUTO the machine can be switched on

and off by the power tool connected. Dirt is picked

up from the source of dust immediately. To comply

with regulations, only approved dust producing tools

should be connected.

The maximum power consumption of the connected

electrical appliance is stated in section “Specifica-

tions”.

Before turning the switch to position AUTO ensure

that the tool connected to the appliance socket is

switched off.

3.3 AutoClean

The machine is equipped with an automatic filter

cleaning system, AutoClean. A frequent cleaning cy-

cle will automatically run during operation to ensure

that suction performance is always at its best.

If suction performance decreases or in extensive

dust applications a manually filter cleaning operation

is recommended:

1. Switch off the machine.

2. Close the nozzles or suction hose opening with

the palm of your hand.

3. Turn the switch to position „I“ and let the ma-

chine operate at full speed for approx. 10 sec-

onds with the suction hose opening closed.

If suction power is still reduced take out the filter and

clean mechanically or replace filter.

For certain applications, like wet pick up, it is recom-

mended to turn off the automatic filter cleaning sys-

tem. For details see chapter 3.1.

3.4 Flow rate warning

CAUTION

Check that all the filters are present and prop-

erly fitted.

The machine is equipped with a system to monitor

air velocity. Before picking up dust with occupational

exposure limit values, check the volume flow moni-

tor.

1. When the motor is running, hold the suction

hose shut to reduce the volume flow. The LED

indicator on front panel will light after approx.

1 second. The acoustic warning sounds after some

additional seconds.

2. Set the diameter setting to the actual hose size.

When LED indicator lights, air velocity is

below 20 m/s.

1. Check if container or filter bag is full.

2. check if air flow is reduced in suction hose, tube/

nozzle, filter.

3.5 Antistatic connection

CAUTION

The machine is equipped with an antistatic

system to discharge any static electricity that

may develop during dust pick-up.

The antistatic system is placed in front part of the

motor top and creates an earth ground connection to

the inlet fitting of the container.

For proper function the use of an electrical conduc-

tive or antistatic suction hose is recommended.

1. When inserting the optional disposal bag make

sure the antistatic connection is kept.

3.6 Cooling air filter

To protect the electronics and motor, the machine is

equipped with a cooling air diffusor. Clean the cool-

ing air diffusor regularly.

For areas with a high concentration of fine dust in

the surrounding air it is recommended to equip the

machine with an optional cooling air filter cartridge to
