Makita M0801 [5/16] Installing or removing drill bit

5 ENGLISH

FUNCTIONAL

DESCRIPTION

Switch action

CAUTION:

• Before plugging in the tool, always check to see

that the switch trigger actuates properly and

returns to the "OFF" position when released.

• Switch can be locked in "ON" position for ease

of operator comfort during extended use. Apply

caution when locking tool in "ON" position and

maintain rm grasp on tool.

► Fig.1: 1. Switch trigger 2. Lock button

To start the tool, simply pull the switch trigger. Tool

speed is increased by increasing pressure on the switch

trigger. Release the switch trigger to stop. For contin-

uous operation, pull the switch trigger, push in the lock

button and then release the switch trigger. To stop the

tool from the locked position, pull the switch trigger fully,

then release it.

Reversing switch action

CAUTION:

• Always check the direction of rotation before

operation.

• Use the reversing switch only after the tool

comes to a complete stop. Changing the direc-

tion of rotation before the tool stops may dam-

age the tool.

• If the switch trigger can not be depressed, check

to see that the reversing switch is fully set to

the

position (A side) or the position (B

side).

► Fig.2: 1. Reversing switch lever

This tool has a reversing switch to change the direc-

tion of rotation. Move the reversing switch lever to

the

position (A side) for clockwise rotation or to

the position (B side) for counterclockwise rotation.

Selecting the action mode

CAUTION:

• Always slide the action mode changing lever all

the way to your desired mode position. If you

operate the tool with the lever positioned half-

way between the mode symbols, the tool may

be damaged.

► Fig.3: 1. Action mode changing lever

This tool has an action mode changing lever. For rota-

tion with hammering, slide the action mode changing

lever to the right (

symbol). For rotation only, slide

the action mode changing lever to the left ( symbol).

ASSEMBLY

CAUTION:

• Always be sure that the tool is switched off and

unplugged before carrying out any work on the

tool.

Installing side grip (auxiliary handle)

CAUTION:

• Always be sure that the tool is switched off and

unplugged before installing or removing the side

grip.

► Fig.4: 1. Grip base 2. Teeth 3. Side grip (auxiliary

handle) 4. Protrusion 5. Loosen 6. Tighten

Always use the side grip to ensure operating safety.

Install the side grip so that the teeth on the grip t in

between the protrusions on the tool barrel.

Then tighten the grip by turning clockwise at the desired

position. It may be swung 360° so as to be secured at

any position.

NOTE: The side grip cannot swing 360° when the

depth gauge is installed.

Installing or removing drill bit

CAUTION:

• Always be sure that the tool is switched off and

unplugged before installing or removing the bit.

► Fig.5: 1. Drill chuck 2. Chuck key

To install the bit, place it in the chuck as far as it will go.

Tighten the chuck by hand. Place the chuck key in each

of the three holes and tighten clockwise. Be sure to

tighten all three chuck holes evenly. To remove the bit,

turn the chuck key counterclockwise in just one hole,

then loosen the chuck by hand.

After using the chuck key, be sure to return it to the

original position.

Depth gauge (optional accessory)

► Fig.6: 1. Side grip 2. Depth gauge 3. Grip base

4. Hex bolt

The depth gauge is convenient for drilling holes of

uniform depth. Install the depth gauge by the following

sequence.

1. Turn the side grip counterclockwise to loosen the

hex bolt.

2. Insert the depth gauge and adjust the depth of

hole.

3. Turn the side grip clockwise so that the depth

gauge and the grip base are xed on the tool

completely.

NOTE: The depth gauge cannot be used at the posi-

tion where the depth gauge strikes against the tool

body.
