Network Remote Control

for LED 5 series 32-46 inches

Turn on/off or give permission to Samsung mobile phones devices to connect

with and control the TV.

You must have a Samsung Mobile phone/device which supports Network Remote

Control. For more details, refer to each device’s manual.

English
