Samsung UE-22D5020 NW [60/191] You can attach your tv to your lan by connecting the lan port on the back of your tv to a ip sharer which is connected to an external modem use lan cable for the connect...
![Samsung UE-22D5020 NW [60/191] You can attach your tv to your lan by connecting the lan port on the back of your tv to a ip sharer which is connected to an external modem use lan cable for the connection see the diagram below](/views2/1000920/page60/bg3c.png)
◀ ▶
◀
●
You can attach your TV to your LAN by connecting the LAN port on the back
of your TV to a IP Sharer which is connected to an external modem. Use LAN
cable for the connection. See the diagram below.
The Modem Port on the Wall
External Modem
(ADSL / VDSL / Cable TV)
IP Sharer
(having DHCP server)
TV Rear Panel
LAN Cable
LAN Cable
Modem Cable
English
English
