Samsung UE-22D5020 NW [150/191] Switching between anynet devices

◀ ▶

◀

❑ Switching between Anynet+ Devices

1. Press the TOOLS button, then select Anynet+ (HDMI-CEC).

Anynet+ devices connected to the TV are listed in Device List.

If you cannot ﬁnd a device you want, press the

C B D

button to refresh the list.

3. Select a device and press the ENTER

button. You can switch to the selected

device.

Only when you set Anynet+ (HDMI-CEC) to On in the System menu, the

Device List menu appears.

●

Switching to the selected device may take up to 2 minutes. You cannot

cancel the operation during the switching operation.

●

If you have selected external input mode by pressing the SOURCE

button, you cannot use the Anynet+ function. Make sure to switch to an

Anynet+ device by using the Device List.
