- 4 -
B550 GAMING X Motherboard Layout
Box Contents
5 B550 GAMING X motherboard 5 User's Manual
5 Motherboard driver disc 5 Two SATA cables
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
KB_MS_USB
DVI
HDMI
U32
QFLASH_PLUS
QFLED
U32G2_LAN
ATX
AUDIO
DDR4_A1
DDR4_A2
DDR4_B1
DDR4_B2
ATX_12V
AMD B550
CLR_CMOS
M_BIOS
PCIEX2
PCIEX1_1
PCIEX1_2
PCIEX1_3
PCIEX16
SYS_FAN2
CODEC
B550 GAMING X
F_USB2 F_U32SYS_FAN3
TPM F_USB1 F_PANEL
D_LED2
LED_C1
LED_C2
D_LED1
F_AUDIO
SYS_FAN1
LED_CPU
CPU_FAN
iTE
®
Super I/O
M2A_CPU
4280 60110
M2B_SB
4280 60110
SATA3
1 0
SATA3
3 2
BAT
Realtek
®
GbE LAN
Socket AM4
CPU_OPT
