- 4 -
B550M AORUS PRO Motherboard Layout
Box Contents
5 B550M AORUS PRO motherboard 5 Two SATA cables
5 Motherboard driver disc
5 User's Manual
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
USB20
DP_HDMI
U32G2C
U32_2
U32_1
U32G2_LAN
ATX
AUDIO
DDR4_A1
DDR4_A2
DDR4_B1
DDR4_B2
ATX_12V
AMD B550
CLR_CMOS
M_BIOS
PCIEX4
PCIEX16
SYS_FAN2
CODEC
B550M AORUS PRO
F_PANEL
F_USB1 F_U32
SYS_FAN3 F_USB2
D_LED2
LED_C1
LED_C2
D_LED1
F_AUDIO
SYS_FAN1
LED_CPU
CPU_OPT
iTE
®
Super I/O
M2A_CPU
4280110
M2B_SB
4280
SATA3
2 0
3 1
BAT
Realtek
®
GbE LAN
Socket AM4
CPU_FAN
60
60
TPM
COM
USB 2.0 Hub
PCIEX1
QFLASH_PLUS
QFLED
