Gigabyte W480 VISION D [102/120] 1 2 configuring s pdif out

Appendix

- 102 -

TheS/PDIFOutjackcantransmitaudiosignalstoanexternaldecoderfordecodingtogetthebestaudioquality.

1. Connecting a S/PDIF Out Cable:

ConnectaS/PDIFopticalcabletoanexternaldecoderfortransmittingtheS/PDIFdigitalaudiosignals.

ConnectstoaS/PDIFopticalcable

6-1-2 ConguringS/PDIFOut

2. Configuring S/PDIF Out:

On the Realtek Digital Output screen, Select the sample

rate and bit depth in the Default Format section.
