Gigabyte W480 VISION D [23/120] Line out front speaker out
![Gigabyte W480 VISION D [23/120] Line out front speaker out](/views2/1920111/page23/bg17.png)
- 23 -
Hardware Installation
Line Out/Front Speaker Out
The line out jack. This jack supports audio amplifying function. For better sound quality, it is recommended
thatyouconnectyourheadphone/speakertothisjack(actualeffectsmayvarybythedevicebeingused).
Mic In/Side Speaker Out
The Mic in jack.
AudioJackCongurations:
Jack
Headphone/
2-channel
4-channel 5.1-channel 7.1-channel
Center/SubwooferSpeakerOut
a a
RearSpeakerOut
a a a
LineIn/SideSpeakerOut
a
LineOut/FrontSpeakerOut
a a a a
MicIn/SideSpeakerOut
a
• ToenableorconguretheaudioamplifyingfunctionfortheLineoutjack,pleaseaccesstheHD
Audio Manager application.
• If you want to install a Side Speaker, you need to retask either the Line in or Mic in jack to be Side
Speaker out using the HD Audio Manager application.
• Referto the instructionson setting up a 2/4/5.1/7.1-channelaudio conguration in Chapter 6,
"Conguring2/4/5.1/7.1-ChannelAudio."
