- 72 -
Conguring a RAID Set
Recovery Volume Options
Intel
®
RapidRecoverTechnologyprovidesdataprotectionbyallowinguserstoeasilyrestoredataandsystem
operationusingadesignatedrecoverydrive.WiththeRapidRecoveryTechnology,whichemploysRAID1
functionality, users can copy the data from the master drive to the recovery drive; if needed, the data on the
recovery drive can be restored back to the master drive.
Before you begin:
• The recovery drive must have equal or greater capacity than the master drive.
• Arecoveryvolumecanbecreatedwithtwoharddrivesonly.ArecoveryvolumeandaRAIDarraycannot
co-exist in the system at the same time, that is, if you have already created a recovery volume, you are
unabletocreateaRAIDarray.
• By default, only the master drive can be viewed in the operating system; the recovery drive is hidden.
Step 1:
Select Create RAID Volume in MAIN MENU and press <Enter> (Figure 19).
Figure 19
Figure 20
Step 2:
After entering the volume name, select Recovery under the RAID Level item and press <Enter> (Figure 20).
Intel(R) Rapid Storage Technology - Option ROM - 17.8.0.4507
Copyright (C) Intel Corporation. All Rights Reserved.
RAID Volumes :
None dened.
Physical Disks :
ID Drive Model Serial # Size Type/Status(Vol ID)
1 TOSHIBA DT01ACA1 763ZLL4FS 931.5GB Non-RAID Disk
2 TOSHIBA DT01ACA1 763ZM7MFS 931.5GB Non-RAID Disk
[
hi
]-Select [ESC]-Exit [ENTER]-Select Menu
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
4. Recovery Volume Options
5. Acceleration Options
6. Exit
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
Intel(R) Rapid Storage Technology - Option ROM - 17.8.0.4507
Copyright (C) Intel Corporation. All Rights Reserved.
Recovery: Copies data between a master and a recovery disk.
[
hi
]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
[ HELP ]
Name : Volume0
RAID Level : Recovery
Disks : Select Disks
Strip Size : N/A
Capacity : 931.5 GB
Sync : Continuous
Create Volume
[ CREATE VOLUME MENU ]
