1-9

8. HDMI

port. This port is for a High-Denition Multimedia Interface (HDMI

) connector,

and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected

content.

9. USB 3.2 Gen 1 (up to 5Gbps) port. This Universal Serial Bus (USB) port connects to

a USB 3.2 Gen 1 device.

10. USB 3.2 Gen 2 (up to 10Gbps) ports (USB Type-C

). This Universal Serial Bus 3.2

(USB 3.2) port is for a USB 3.2 Gen 2 Type-C

device.

11. Optical S/PDIF out port. This port allows you to connect your PC to amplied

speakers, headphones, or Sony/Phillips Digital Interconnect Format (S/PDIF) compliant

devices.

12. Microphone port (pink). This port connects a microphone.

13. Line Out port (lime). This port connects a headphone or a speaker. In 4-channel,

5.1-channel, and 7.1-channel congurations, the function of this port becomes Front

Speaker Out.

Refer to the audio conguration table below for the function of the audio ports in 2, 4, 5.1,

or 7.1-channel conguration.

Audio 2, 4, 5.1 or 7.1-channel configuration

Port 2-channel 4-channel 5.1-channel 7.1-channel

Light Blue

(Rear panel)

- - - Side Speaker Out

Lime

(Rear panel)

Front Speaker Out Front Speaker Out Front Speaker Out Front Speaker Out

Pink

(Rear panel)

- - - -

Black

(Rear panel)

- Rear Speaker Out Rear Speaker Out Rear Speaker Out

Orange

(Rear panel)

- -

Center/

Subwoofer

Center/

Subwoofer
