![ASRock B760M PG SONIC WiFi [12/60] English](/views2/1921002/page12/bgc.png)
English
8
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 ATX 12V Power Connector (ATX12V2)
3 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)
4 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2)
5 CPU Fan Connector (CPU_FAN1)
6 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
7 Post Status Checker (PSC)
8 Addressable LED Header (ADDR_LED2)
9 Addressable LED Header (ADDR_LED3)
10 ATX Power Connector (ATXPWR1)
11 USB 3.2 Gen1 Header (USB32_6_7)
12 Front Panel Type C USB 3.2 Gen2 Header (USB32_TC2)
13 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
14 SATA3 Connectors (SATA3_0)(Upper), (SATA3_1)(Lower)
15 SATA3 Connectors (SATA3_2)(Upper), (SATA3_3)(Lower)
16 System Panel Header (PANEL1)
17 Chassis Intrusion and Speaker Header (SPK_CI1)
18 SPI TPM Header (SPI_TPM_J1)
19 USB 2.0 Header (USB_5_6)
20 USB 2.0 Header (USB_3_4)
21 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
22 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
23 RGB LED Header (RGB_LED1)
24 Addressable LED Header (ADDR_LED1)
25 Clear CMOS Jumper (CLRMOS1)
26 Front Panel Audio Header (HD_AUDIO1)
27 eDP Signal Connector (EDP1)
