ASRock B760M PG SONIC WiFi [6/60] Memory
![ASRock B760M PG SONIC WiFi [6/60] Memory](/views2/1921002/page6/bg6.png)
English
2
1.2 Specications
Platform
•
Micro ATX Form Factor
•
2oz Copper PCB
CPU
•
Supports 13
th
Gen & 12
th
Gen Intel® Core
TM
Processors
(LGA1700)
•
Supports Intel® Hybrid Technology
•
Supports Intel® Turbo Boost Max 3.0 Technology
•
Supports Intel® ermal Velocity Boost (TVB)
•
Supports Intel® Adaptive Boost Technology (ABT)
Chipset
•
Intel® B760
Memory
•
Dual Channel DDR5 Memory Technology
•
4 x DDR5 DIMM Slots
•
Supports DDR5 non-ECC, un-buered memory up to
6800+(OC)*
•
Max. capacity of system memory: 128GB
•
Supports Intel® Extreme Memory Prole (XMP) 3.0
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
Expansion
Slot
CPU:
•
1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
Chipset:
•
1 x PCIe 4.0 x1 Slot (PCIE2)*
•
1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe
WiFi module and Intel® CNVio/CNVio2 (Integrated WiFi/
BT)
* Supports NVMe SSD as boot disks
•
15μ Gold Contact in VGA PCIe Slot (PCIE1)
Graphics
•
Intel® UHD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
•
Intel® X
e
Graphics Architecture (Gen 12)
