ASRock B760M-ITX/D4 WiFi [3/46] Contents
![ASRock B760M-ITX/D4 WiFi [3/46] Contents](/views2/1921014/page3/bg3.png)
Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Motherboard Layout 6
1.4 I/O Panel 8
1.5 Block Diagram 9
1.6 802.11ax Wi-Fi 6E Module and ASRock WiFi 2.4/5/6 GHz
Antennas 10
Chapter 2 Installation 12
2.1 Installing the CPU 13
2.2 Installing the CPU Fan and Heatsink 15
2.3 Installing Memory Modules (DIMM)
16
2.4 Connecting the Front Panel Header 18
2.5 Installing the I/O Panel Shield 19
2.6 Installing the Motherboard 20
2.7 Installing SATA Drives 21
2.8 Installing a Graphics Card 23
2.9 Connecting Peripheral Devices 25
2.10 Connecting the Power Connectors 26
2.11 Power On 27
2.12 Jumpers Setup 28
2.13 Onboard Headers and Connectors 29
2.14 M.2 SSD Module Installation Guide (M2_1) 36
