4
Rear Panel
I/O
•
2 x Antenna Ports
•
1 x HDMI Port
•
1 x DisplayPort 1.4
•
1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)
•
2 x USB 3.2 Gen1 Ports
•
2 x USB 2.0 Ports
•
1 x RJ-45 LAN Port
•
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
CPU:
•
1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280
PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
•
4 x SATA3 6.0 Gb/s Connectors
* Supports Intel® Volume Management Device (VMD)
* Supports NVMe SSD as boot disks
RAID
•
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
Connector
•
1 x CPU Fan Connector (4-pin)*
•
1 x Chassis Fan Connector (4-pin)*
•
1 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)**
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector
•
1 x Front Panel Audio Connector
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
•
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
* CPU_FAN1 and CHA_FAN2 support the fan power up to 1A
(12W).
** CHA_FAN1/WP support the fan power up to 2A (24W).
** CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in
use.
BIOS
Feature
•
AMI UEFI Legal BIOS with GUI support
