3
B760M-ITX/D4 WiFi
Graphics
•
Intel® UHD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
•
Intel® X
e
Graphics Architecture (Gen 12)
•
1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and
max. resolution up to 4K 60Hz
•
1 x DisplayPort 1.4 with DSC (compressed), supports HDCP
2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
Audio
•
7.1 CH HD Audio (Realtek ALC897 Audio Codec)
•
Nahimic Audio
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
Realtek RTL8111H
Wireless
LAN
•
802.11ax Wi-Fi 6E Module
•
Supports IEEE 802.11a/b/g/n/ac/ax
•
Supports Dual-Band 2x2 with extended 6GHz band* sup-
port
* Wi-Fi 6E (6GHz band) will be supported by Microso® Win-
dows® 11. e availability will depend on the dierent regula-
tion status of each country and region. It will be activated (for
supported countries) through Windows Update and soware
updates once available.
* A 6GHz compatible router is required for 6E functionality.
•
2 antennas to support 2 (Transmit) x 2 (Receive) diversity
technology
•
Supports Bluetooth + High speed class II
•
Supports MU-MIMO
USB
•
1 x USB 3.2 Gen2x2 Type-C (Rear)
•
4 x USB 3.2 Gen1 (2 Rear, 2 Front)
•
6 x USB 2.0 (2 Rear, 4 Front)
* All USB ports support ESD Protection
