1.2 Specications
Platform
•
Mini-ITX Form Factor
CPU
•
Supports 13
th
Gen & 12
th
Gen Intel® Core
TM
Processors
(LGA1700)
•
Supports Intel® Hybrid Technology
•
Supports Intel® Turbo Boost Max 3.0 Technology
•
Supports Intel® ermal Velocity Boost (TVB)
•
Supports Intel® Adaptive Boost Technology (ABT)
Chipset
•
Intel® B760
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 DIMM Slots
•
Supports DDR4 non-ECC, un-buered memory up to
5333+(OC)*
1DPC 1R Up to 5333+ MHz (OC), 3200 MHz Natively.
1DPC 2R Up to 4266+ MHz (OC), 3200 MHz Natively.
•
Supports ECC UDIMM memory modules (operate in non-
ECC mode)
•
Max. capacity of system memory: 64GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
Expansion
Slot
CPU:
•
1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
Chipset:
•
1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/
BT PCIe WiFi module and Intel® CNVio/CNVio2 (Integrated
WiFi/BT)
