GB7
GB
4. Instructions for maintenance and storage
4.1 Make sure that the nuts, bolts and screws are tight.
4.2 Be careful when adjusting - danger of injuries. Do not trap your fin-
gers between the housing and the blade. Wear protective gloves.
4.3 Never store the lawn tractor with fuel in the tank inside a building
in which petrol fumes can possibly come into contact with naked
flames or with sparks
- danger of explosion!
4.4 Only empty the petrol tank in the open.
4.5 Allow the engine to cool down before you put the machine into an
enclosed area.
4.6 Avoid the risk of a fire by keeping the engine and the exhaust free
of grass, leaves and grease (oil).
4.7 Check regularly to make sure that the grass box is in a satisfactory
condition.
4.8 For safety's sake, worn or damaged parts must be replaced imme-
diately.
4.9 Replacement blades and additional appliances may only be moun-
ted on the lawn tractors intended for this purpose according to the
manufacturer's instructions. This is the only way to maintain the
safety and the performance of your lawn tractor.
4.10 Please ensure that the maintenance, checking and sharpening of
the blade is only done by an authorised dealer.
4.11 Use original spare parts and accessories only.
We would point out that we are not liable according to the Product
Liability Act for damage caused by our machine as a result of
a) improper repairs not carried out by our authorised service
agents,
b) or if ORIGINAL SPARE PARTS are not used as replacement
parts.
The same applies to accessories. A service booklet with the
addresses of our authorised service agents is enclosed with the
appliance.
Unpacking Lawntractor
The lawntractor will be delivered on a solid wood pallet.
To remove the packing, place the pallet on a level surface.
Please follow the sequence for unpacking and for the respective
wheel locks.
Open cardboard packing at top.
Remove staples and take off cardboard packing upward.
Remove enclosed parts and packing materials.
Remove wooden hoop.
Remove front laths.
Remove wooden blocks.
Remove all nails on the pallet.
Move mowing unit into highest position.
See operating instructions under:
>> Start-up - Adjusting cutting height <<
Lift tractor at rear and push off pallet.
Dispose of pallet and packing materials properly.
Secure the tractor from rolling away with the wheel
locks!
Now you can begin mounting equipment.
