11
en
Figure
Pet hair tool
Floor tool for easy, thorough removal of pet hair
To clean the nozzle, simply vacuum it using the fixed /
telescopic tube
Figure
Once you have switched off the vacuum cleaner, slide
the catch on the floor too into the groove at the rear of
the appliance.
Once you have switched off the vacuum cleaner, slide
the catch on the floor tool into the groove on the rear of
the appliance.
!
Attention: Do not operate in an upright/vertical
position.
Figure
The appliance can also be carried using the carrying handle
when vacuuming steps, for example.
When the work is done
Figure
Unplug the vacuum cleaner.
Tug the power cord briefly and let go. The cable then
rewinds automatically.
Figure
Unlock the telescopic tube by moving the sliding button
in the direction of the arrow and slide one tube into the
other.
Emptying the dust container
To achieve optimum vacuuming results, the dust container
should be emptied each time the vacuum cleaner is used
or, at the latest, when the maximum fill level is reached.
After each use, check the fluff filter, particulate filter and
motor protection filter. Clean the filters by tapping out the
dust or rinsing them, as necessary.
Figure
Use the release button to unlatch the twin cylinders and
open them forwards.
Figure
Remove the dust container from the appliance.
Figure
Press the button to release the dust container flap and
empty the container into the rubbish bin. The flap
engages when tilted backwards.
22
21
20
19*
18
17
16
15*
Figure
Fold the flap back and close the dust container.
Insert the dust container into the appliance.
Fold the dual separator back into position making sure
that it engages.
Cleaning the particle filter
Figure
Release the dual separator and fold it forwards.
(See fig. 20)
Remove the particulate filter with fluff filter and clean by
knocking out the dirt.
To do so, take off the fluff filter then release and open the
flap on the particulate filter cartridge.
The components of the particulate filter system should
be rinsed at least once every quarter. The fluff filter and
particulate filter can be cleaned in the washing machine
at 30°C on a delicates cycle.
After cleaning, close the flap on the particulate filter
cartridge and engage at the side. Place the fluff filter on
the particulate filter cartridge.
!
Attention: The twin cylinders can only be engaged
when the particle filter is fitted. The filter must be
completely dry before it is refitted in order to ensure
that it functions correctly and to prevent the formation
of odours or bacteria.
Cleaning the motor protection filter
The motor protection filter should be cleaned regularly and
at least once every 3 months by knocking out the dirt and
rinsing.
Figure
Unlatch the twin cylinders and open them forwards.
(See fig. 20)
Remove the dust container from the appliance
(see fig. 21).
Pull out the motor protection filter in the direction of the
arrow.
Clean the motor protection filter by tapping it.
If it is very dirty, the motor protection filter should be rin-
sed. The motor protection filter can even be cleaned in
the washing machine at 30 °C on a delicates cycle.
The filter must then be left to dry for at least 24 hours.
After cleaning, slide the motor protection filter into the
vacuum cleaner.
Insert the dust container into the appliance.
Fold the dual separator back into position making sure
that it engages.
!
Attention: The filter must be completely dry before it
is refitted in order to ensure that it functions correctly
and to prevent the formation of odours or bacteria.
25
24
23
*
Depending on equipment
