Thank you for your purchase of a 1 NIKKOR VR 10-30mm f/3.5-5.6 lens. Before using this product, please

carefully read both these instructions and the camera manual.

Note: 1 NIKKOR lenses are exclusively for Nikon 1 interchangeable lens format digital cameras. The

angle of view is equivalent to a 35 mm format lens with a focal length about 2.7 × longer.

■ Attachment and Removal

See the camera manual.

Note: Be careful not to press the retractable lens

barrel button while attaching or removing the lens.

■ Retractable Lens Mechanism

To unlock the zoom ring and extend the lens for

use, press the retractable lens barrel button (1)

and rotate the zoom ring in the direction shown

in Figure 2. The lens can be retracted and the

zoom ring locked by pressing the retractable lens

barrel button and rotating the zoom ring in the

opposite direction.

■ Zoom

Use the zoom ring to zoom in and out.

Photographs can be taken only when the focal

length scale is between 10 and 30 mm.
