FIRST Austria FA-2410 [2/16] English

DIGITAL ALARM CLOCK

INSTRUCTION MANUAL

CONTROLS AND INDICATORS

1. Minute set button

2. Time set button

3. Hour set button

4. Alarm set button

5. Snooze button

6. Alarm on/off switch

7. Battery compartment

8. LED Display

9. AC power cord

10. Alarm off button

1. CONNECTING THE POWER

Insert correctly wired plug into a power outlet. The clock display will blink showing that the time

is not correct. It will also blink if there has been a power cut and no back up battery is tted.

2. TO SET THE TIME

2.1 Press and hold the time set button (2).

2.2 Press the minute set button (1) or hour set button (3) to set the clock display to the correct

time.

2.3 Release the time set button (2).

3. TO SET THE ALARM TIME

3.1 Press and hold the alarm set button (4).

3.2 While holding the alarm set button (4) press the hour set button (3) and minute set button

(1) to advance the time until the desired alarm time is shown on the display.

NOTE: To check up the wake-up time, press the alarm set button (4). The clock display will show

the preset alarm time.

4. WAKE TO BUZZER ALARM

4.1 Set the alarm on/off switch (6) to ON position. The respective AUTO indicator will light on.

The buzzer will now be switched on automatically at the selected alarm time for 1 hour and

59 minutes.

4.2 Press the alarm off button (10) to turn off the buzzer, the alarm will be activated again after

24 hours.

4.3 Slide the alarm on/off switch (6) to deactivate the alarm function completely.

5. SNOOZE OPERATION

To obtain approximately 9 more minutes of sleep, press snooze set button (5) after the buzzer

works at the preset wake-up time. This will silence the buzzer for about 9 minutes.

6. BATTERY BACK UP

NOTE: The clock has a back up power system to ensure continuous operation of the alarm and

clock in the event of a power failure. The switch from AC to battery power is automatic. However,

under battery power the clock display will not illuminate even through the clock will maintain

approx. the current time and will store the alarm time in its memory. The system operates on a

9V battery (not included). We recommended the use of a long life battery to ensure maximum

performance.

NOTE: This battery back up features is intended to retain the clock time and memory functions

during a power failure for short periods. The clocks should not be left for long periods of time

without mains supply as the battery will drain fairly quickly. Remove the battery if the unit is

disconnected from the mains.

CARE: The cabinet can be dusted with soft cloth or if necessary cleaned with a soft cloth

dampened with water. The power plug should be disconnected before cleaning. Never use

polish, solvent, abrasives or strong detergents on the cabinet since these can damage the nish.

SPECIFICATIONS:

POWER SOURCE: AC 230V/50Hz

Dripping warning:

The product shall not be exposed to dripping or splashing and that no objects lled with liquids,

such as vases, shall be placed on the product.

Ventilation warning:

The normal ventilation of the product shall not be impeded for intended use.

Disconnect device warning:

“Main plug is used as connection, so it should always remain ready operate.”

Environment friendly disposal

You can help protect the environment! Please remember to respect the local regulations: hand in

the non-working electrical equipments to an appropriate waste disposal center.

ENGLISH

3. 4. 10. 9.

7. 8.
