CS1842 / CS1844 User Manual
4
Requirements
Console
Two HDMI monitors capable of the highest possible resolution
A USB mouse
A USB keyboard
Microphone and speakers
Computers
The following equipment must be available on each computer:
Two HDMI ports
Four HDMI ports for Quad-Display (DCC mode)
A USB Type-A port
Audio ports
Cables
To guarantee video quality, we recommend using only ATEN HDMI KVM
cables. Four (CS1842) or eight (CS1844) cables are provided with this
package.
Note: The quality of the display is affected by the quality of the cables.We
recommend the total length from the source to the monitor to not exceed
6 meters (3 meters between the PC and the KVM switch. 3 meters
between the KVM switch and the monitor). If you need additional
cables, please contact your dealer to purchase ATEN approved cables.
Operating Systems
Windows
Mac
Linux
