Aten CS1844 [22/88] Refer to buzzer control on page 29 if you wish to turn the buzzer on or off

CS1842 / CS1844 User Manual

Buzzer Behavior

To diagnose which task the CS1842 / CS1844 is performing through the

buzzer, please refer to the table below.

Refer to Buzzer Control on page 29 if you wish to turn the buzzer on or off.

Sound Description

1 beep



Changing port



Activating auto-scan mode



Pausing/resuming auto-scan

1 long beep



Powering on the unit



Resetting the unit

2 beeps



Interrupting auto-scan



Entering keyboard emulation off mode



Finishing USB synchronization
