Aten CS1844 [21/88] Mode selection pushbutton and mode led behavior

Chapter 1. Introduction

Mode Selection Pushbutton and Mode LED Behavior

Pressing the Mode Selection Pushbutton different number of times will light up

different Mode LED, which allows for the follow-up action shown in the table.

For more information on the follow-up actions, please refer to Manual

Switching on page 17.

Button Press Mode LED that Lights up Follow-Up Action

Once

KVM, Audio, USB Press any of the port selection

pushbutton to select focus for all

connectors

Twice

KVM Press any of the port selection

pushbutton to select focus for KVM

connector

Three times

Audio Press any of the port selection

pushbutton to select focus for audio

connectors

Four times

USB Press any of the port selection

pushbutton to select focus for USB

link
