Aten CS18216 [41/112] Powering off and restarting

3. Basic Operation

Powering Off and Restarting

If it becomes necessary to power off a CS18208 / CS18216, do the following

before restarting it:

1. Unplug the CS18208 / CS18216 from its power source.

2. Shut down all the computers that are attached to it.

Note: Unplug the power cords of any computers that have the Keyboard

Power On function. Otherwise, the CS18208 / CS18216 will still

receive power from the computers.

3. Wait 10 seconds, then plug the CS18208 / CS18216 back in.

4. Power on the computers.

Note: If there are stations cascaded down from the primary CS18208 /

CS18216, all the cascaded stations and the computers attached to

them must be shut down as well.
