Chapter 7. RS-232 Operation
71
OSD Hotkey
The OSD Hotkey command allows you to change the hotkey used to invoke the
OSD. The default hotkey is [Scroll][Scroll].
Use the Formula - to set Parameters - to create a Command.
Formulas:
Command + Control + [Enter]
Parameters:
Hotkey Switching Commands
The available formulas for OSD Hotkey commands are as follows:
1. Command + Control + [Enter]
For example, to change the OSD hotkey invoke key to [Scroll] [Scroll], type
the following:
osdkey scroll [Enter]
2. Command + Control + [Enter]
For example, to change the OSD hotkey invoke key to [Ctrl] [Ctrl], type the
following:
osdkey ctrl [Enter]
Command Description
osdkey OSD Hotkey Command
Control Description
scroll Change OSD hotkey invoke key to:
[Scroll] [Scroll] (Default)
ctrl Change OSD hotkey invoke key to:
[Ctrl] [Ctrl]
Enter Description
Enter Enter and send out command
