Chapter 5. Hotkey Operation
45
then restarted Auto Scanning, it starts, at the beginning, from the first
computer on the installation.
To resume Auto Scanning, press any key. Scanning continues from the
computer you paused at.
While the Auto Scan mode is operating, ordinary keyboard and mouse
functions are suspended - only Auto Scan mode compliant keystrokes
can be input. You must exit Auto Scan mode to regain normal control
of the console.
Exiting Auto Scan
To exit Auto Scan mode press
[Esc]
or
[Spacebar]
. Auto Scanning
stops when you exit Auto Scan mode.
