KH1508A / KH1516A / KH1532A User Manual
vi
Package Contents
Check to make sure that all the components are in working order. If you
encounter any problem, please contact your dealer.
The KH1508A / KH1516A / KH1532A package consists of:
1 KH1508A, KH1516A, or KH1532A Cat 5 High-Density KVM Switch
1 firmware upgrade cable
1 power cord
1 mounting kit
1 foot pad set (4 pcs)
1 user instructions
