![Aten KH1532A [83/90] Appendix](/views2/1977329/page83/bg53.png)
Appendix
71
Specifications
Function KH1508A KH1516A KH1532A
Computer
Connections
Direct 8 16 32
Max. 256 (via Daisy
Chain)
512 (via Daisy
Chain)
1024 (via Daisy
Chain)
Port Selection OSD (On Screen Display);
Hotkeys
Pushbuttons
Connectors Console KB 1 x 6-pin Mini-DIN F (Purple)
1 x USB Type-A Female
Video 1 x HDB-15 F (Blue)
Mouse 1 x 6-pin Mini-DIN F (Green)
1 x USB Type-A Female
KVM Ports 8 x RJ-45 16 x RJ-45 32 x RJ-45
Daisy
Chain
In
1 x DB-25 F (Black)
Out
1 x DB-25 M (Black)
F/W Upgrade 1 x RJ-11 F (Black)
Power 3-Prong AC socket
Switches Port Selection 8 x Pushbutton 16 x Pushbutton 32 x Pushbutton
KVM Reset 1 x Semi-recessed pushbutton
F/W Upgrade 1 x Slide
Power 1 x Rocker
LEDs Port
On Line
8 (Green) 16 (Green) 32 (Green)
Selected
8 (Orange) 16 (Orange) 32 (Orange)
Power 1 (Blue)
Station ID 1 x 2 Digit 7-segment (Orange)
Emulation Keyboard PS/2; USB
Mouse PS/2; USB
Scan Interval 1–255 sec.
Video 1920 x 1200 @ 60 Hz (30 m);
1600 x 1200 @ 60 Hz (40 m);
1280 x 1024 @ 75 Hz (50 m)
I/P Rating 100-240 VAC; 50/60 Hz; 1A
Power Consumption AC110V:5.1W:3
2BTU
AC220V:5.1W:3
2BTU
AC110V:5.3W:3
3BTU
AC220V:5.3W:3
3BTU
AC110V:4.6W:3
0BTU
AC220V:4.8W:3
1BTU
