![Aten KN1132V [19/334] Overview](/views2/1977332/page19/bg13.png)
1
Chapter 1
Introduction
Overview
The KN2116VA / KN4116VA / KN2124VA / KN4124VA / KN1132V /
KN2132VA / KN4132VA / KN8032VB / KN8132V / KN2140VA /
KN4140VA / KN4164V / KN8064VB / KN8164V switches are IP-based
KVM control units that allow both local and remote operators to monitor and
access multiple servers from a single console. This series of KVM over IP
Switches can control up to 16/24/32/40/64 servers, and by cascading
compatible KVM switches, as many as 512 servers can be controlled on a
complete two-stage installation. In addition, up to 4 KVM over IP Switches can
be centralized and controlled by a single CM1164A or CM1284. Each KVM
over IP switch features superior video quality (Full HD resolution of 1920 x
1200), FIPS 140-2 with level 1 security standards and virtual media
transmissions at twice the speed. The KN series provides local console and
remote over IP access for users to monitor and access their entire data center
over a network. In addition, it offers out-of-band access with external modem
support for BIOS-level troubleshooting when the network is down.
These KN series of KVM over IP Switches are differentiated according to the
number of buses they support and the number of KVM ports they provide – as
shown below:
Model Bus Support KVM Ports
KN2116VA 1 Local; 2 Remote; 1U 16
KN4116VA 1 Local; 4 Remote; 1U 16
KN8116V 1 Local; 8 Remote; 1U 16
KN2124VA 1 Local; 2 Remote; 1U 24
KN4124VA 1 Local; 4 Remote; 1U 24
KN1132V 1 Local; 1 Remote; 1U 32
KN2132VA 1 Local; 2 Remote; 1U 32
KN4132VA 1 Local; 4 Remote; 1U 32
KN8032VB 8 Shared Local and Remote; 1U 32
KN8132V 1 Local; 8 Remote; 1U 32
KN2140VA 1 Local; 2 Remote; 1U 40
KN4140VA 1 Local; 4 Remote; 1U 40
KN4164V 1 Local; 4 Remote; 2U 64
