Appendix
273
KN8032VB / KN8064VB
Function KN8032VB KN8064VB
Computer
Connections
Direct 32 64
Max 512 (via Cascade KVM Switches)
Console
Connections
Local 1 (Shared)
Remote 8 8
Port Selection Pushbutton / GUI / Hotkey
Connectors Console
Port
Keyboard 1 x USB Type A Female (White)
Video 1 x HDMI Female (Black)
1 x VGA HDB-15 (Blue)
Mouse 1 x USB Type A Female (White)
Audio 2 x Audio Jack Female (Pink; Green)
LUC Port 1 x USB Mini-B Female (Black)
KVM Port 32 x RJ-45 Female (Black) 64 x RJ-45 Female (Black)
Power 2 x IEC 60320/C14
LAN 2 x RJ-45 Female (Black)
USB
(Console/Virtual
Media)
3 x USB Type A Female (White)
Serial 1 x RJ-45 Female (Black)
PON 1 x RJ-45 Female (Black)
Switches Reset 1 x Semi-recessed Pushbutton
Power 2 x Rocker Switches
Port Selection 2 x Pushbuttons
LEDs Online / Selected 32 (Green / Orange) 64 (Green / Orange)
Power 2 (Green)
Link
10 / 100 / 1000 Mbps
2 (Red / Orange / Green)
Emulation Keyboard / Mouse PS/2 / USB
Video Local 1920 x 1200 @ 60 Hz
Remote 1920 x 1200 @ 60 Hz
Scan Interval 1 – 255 secs
I/P Rating 100 – 240 V~, 50 – 60 Hz, 1 A
Power Consumption AC 110 V, 64.7 W, 357 BTU
AC 220 V, 63.4 W, 351 BTU
AC 110 V, 72.6 W, 394 BTU
AC 220 V, 71.2 W, 387 BTU
