Aten KN1132V [251/334] Port operation

233

Chapter 12

Port Operation

Overview

After you have successfully logged in (see Logging In, page 57), the KVM

over IP switch opens to the Port Access tab’s Connections page, with the first

KVM over IP switch selected in the sidebar:

Note: 1. The WinClient and Java Client AP programs have a hidden Control

Panel at the upper center of the screen that becomes visible when you

mouse over it. The Browser version’s Control Panel only appears

after you switch to a port. The Control Panel is discussed on page 74.

2. See KVM Devices and Ports – Connections Page, page 127 for details

about the Port Access Connections page.
