ATEN Secure KVM User Manual
27
Video Max. 3840 x 2160 @ 30 Hz (UHD)
Scan Interval N/A
I/P Rating 100–240V~ ; 50-60 Hz; 1A
Environment
Operating Temp. 0–50°C
Storage Temp. -20–60°C
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 1.78kg 1.79kg 3.05kg
Dimensions
(L x W x H)
335 x 164 x 44
mm
335 x 164 x 44
mm
432 x 205 x 66
mm
ATEN DisplayPort Dual Display Secure KVM
Function CS1142DP CS1144DP CS1148DP
Computer
Connections
Direct 2 4 8
Max. 2 4 8
Console Connections 1 Direct
Port Selection Pushbutton
Connectors
Console
Ports
Keyboard
1 x 6-pin Mini-DIN Female (Purple)
1 x USB Type A Female (2/4-Port Black; 8-Port White)
Video 2 x HDMI 1.4 Female (Black)
Mouse
1 x 6-pin Mini-DIN Female (Green)
1 x USB Type A Female (2/4-Port Black; 8-Port White)
Speaker 1 x Mini Stereo Jack Female (Green)
Microphone N/A
CAC 1 x USB Type A Female (Black)
KVM
Ports
Keyboard/
Mouse
2 x USB Type-B
Female (White)
4 x USB Type-B
Female (White)
8 x USB Type-B
Female (White)
Video
4x DisplayPort 1.2
Female (Black)
8x DisplayPort 1.2
Female (Black)
16xDisplayPort
1.2 Female (Black)
CAC
2 x USB Type-B
Female (White)
4 x USB Type-B
Female (White)
8 x USB Type-B
Female (White)
Speaker
2 x Mini Stereo
Jack Female
(Green)
4 x Mini Stereo
Jack Female
(Green)
8 x Mini Stereo
Jack Female
(Green)
Microphone N/A
