ATEN Secure KVM User Manual
28
Power 1 x 3-prong AC Socket
Switches
Port 2 x Pushbuttons 4 x Pushbuttons 8 x Pushbuttons
Reset 1 x Semi-recessed Pushbutton
Power 1 x Rocker
LEDs
On Line / Selected 2 (Orange) 4 (Orange) 8 (Orange)
CAC activated 2 (Green) 4 (Green) 8 (Green)
Power 1 (Blue)
Key Lock LED 3 (Green; Num Lock, Caps Lock, Scroll Lock)
Console Video 2 (Green, on back panel)
Emulation Keyboard/Mouse USB
Video Max. 3840 x 2160 @ 30 Hz (UHD)
Scan Interval N/A
I/P Rating 100–240V~ ; 50-60 Hz; 1A
Environment
Operating Temp. 0–50°C
Storage Temp. -20–60°C
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 2.12kg 2.13kg 3.35kg
Dimensions (L x W x H)
335 x 164 x 66
mm
335 x 164 x 66
mm
432 x 205 x 66
mm
ATEN HDMI Single Display Secure KVM
Function CS1182H CS1184H CS1188H
Computer
Connections
Direct 2 4 8
Max. 2 4 8
Console Connections 1 Direct
Port Selection Pushbutton
Connectors
Console
Ports
Keyboard
1 x 6-pin Mini-DIN Female (Purple)
1 x USB Type A Female (2/4-Port Black; 8-Port White)
Video 1 x HDMI 1.4 Female (Black)
Mouse
1 x 6-pin Mini-DIN Female (Green)
1 x USB Type A Female (2/4-Port Black; 8-Port White)
Speaker 1 x Mini Stereo Jack Female (Green)
Microphone N/A
