ATEN Secure KVM User Manual
29
CAC 1 x USB Type A Female (Black)
KVM
Ports
Keyboard/
Mouse
2 x USB Type-B
Female (White)
4 x USB Type-B
Female (White)
8 x USB Type-B
Female (White)
Video
2 x HDMI 1.4
Female (Black)
4 x HDMI 1.4
Female (Black)
8 x HDMI 1.4
Female (Black)
CAC
2 x USB Type-B
Female (White)
4 x USB Type-B
Female (White)
8 x USB Type-B
Female (White)
Speaker
2 x Mini Stereo
Jack Female
(Green)
4 x Mini Stereo
Jack Female
(Green)
8 x Mini Stereo
Jack Female
(Green)
Microphone N/A
Power 1 x 3-prong AC Socket
Switches
Port 2 x Pushbuttons 4 x Pushbuttons 8 x Pushbuttons
Reset 1 x Semi-recessed Pushbutton
Power 1 x Rocker
LEDs
On Line / Selected 2 (Orange) 4 (Orange) 8 (Orange)
CAC activated 2 (Green) 4 (Green) 8 (Green)
Power 1 (Blue)
Key Lock LED 3 (Green; Num Lock, Caps Lock, Scroll Lock)
Video 1 (Green, on back panel)
Emulation Keyboard/Mouse USB
Video Max. 3840 x 2160 @ 30 Hz (UHD); 1920 x 1080 (FHD)
Scan Interval N/A
I/P Rating 100–240V~ ; 50-60 Hz; 1A
Environment
Operating Temp. 0–50°C
Storage Temp. -20–60°C
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 1.78kg 1.79kg 3.05kg
Dimensions (L x W x H)
335 x 164 x 44
mm
335 x 164 x 44
mm
432 x 205 x 66
mm
