ATEN Secure KVM User Manual
30
ATEN HDMI Dual Display Secure KVM
Function CS1142H CS1144H CS1148H
Computer
Connections
Direct 2 4 8
Max. 2 4 8
Console Connections 1 Direct
Port Selection Pushbutton
Connectors
Console
Ports
Keyboard
1 x 6-pin Mini-DIN Female (Purple)
1 x USB Type A Female (2/4-Port Black; 8-Port White)
Video 2 x HDMI 1.4 Female (Black)
Mouse
1 x 6-pin Mini-DIN Female (Green)
1 x USB Type A Female (2/4-Port Black; 8-Port White)
Speaker 1 x Mini Stereo Jack Female (Green)
Microphone
N/A
CAC 1 x USB Type A Female (Black)
KVM Ports
Keyboard/
Mouse
2 x USB Type-B
Female (White)
4 x USB Type-B
Female (White)
8 x USB Type-B
Female (White)
Video
4 x HDMI 1.4
Female (Black)
8 x HDMI 1.4
Female (Black)
16 x HDMI 1.4
Female (Black)
CAC
2 x USB Type-B
Female (White)
4 x USB Type-B
Female (White)
8 x USB Type-B
Female (White)
Speaker
2 x Mini Stereo
Jack Female
(Green)
4 x Mini Stereo
Jack Female
(Green)
8 x Mini Stereo
Jack Female
(Green)
Microphone
N/A
Power 1 x 3-prong AC Socket
Switches
Port 2 x Pushbuttons 4 x Pushbuttons 8 x Pushbuttons
Reset 1 x Semi-recessed Pushbutton
Power 1 x Rocker
LEDs
On Line / Selected 2 (Orange) 4 (Orange) 8 (Orange)
CAC activated 2 (Green) 4 (Green) 8 (Green)
Power 1 (Blue)
Key Lock LED 3 (Green; Num Lock, Caps Lock, Scroll Lock)
Console Video 2 (Green, on back panel)
Emulation Keyboard/Mouse USB
Video Max. 3840 x 2160 @ 30 Hz (UHD); 1920 x 1080 (FHD)
