ATEN Secure KVM User Manual
31
Scan Interval N/A
I/P Rating 100–240V~ ; 50-60 Hz; 1A
Environment
Operating Temp. 0–50°C
Storage Temp. -20–60°C
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 2.12kg 2.13kg 3.35kg
Dimensions (L x W x H)
335 x 164 x 66
mm
335 x 164 x 66
mm
432 x 205 x 66
mm
ATEN DVI Single Display Secure KVM
Function CS1182D CS1184D CS1188D
Computer
Connections
Direct 2 4 8
Max. 2 4 8
Console Connections 1 Direct
Port Selection Pushbutton
Connectors
Console
Ports
Keyboard
1 x 6-pin Mini-DIN Female (Purple)
1 x USB Type A Female (2/4-Port Black; 8-Port White)
Video 1 x DVI-I Dual Link Female (White)
Mouse
1 x 6-pin Mini-DIN Female (Green)
1 x USB Type A Female (2/4-Port Black; 8-Port White)
Speaker 1 x Mini Stereo Jack Female (Green)
Microphone
N/A
CAC 1 x USB Type A Female (Black)
KVM Ports
Keyboard/
Mouse
2 x USB Type-B
Female (White)
4 x USB Type-B
Female (White)
8 x USB Type-B
Female (White)
Video
2 x DVI-I Dual Link
Female (White)
4 x DVI-I Dual Link
Female (White)
8 x DVI-I Dual Link
Female (White)
CAC
2 x USB Type-B
Female (White)
4 x USB Type-B
Female (White)
8 x USB Type-B
Female (White)
Speaker
2 x Mini Stereo
Jack Female
(Green)
4 x Mini Stereo
Jack Female
(Green)
8 x Mini Stereo
Jack Female
(Green)
Microphone
N/A
Power 1 x 3-prong AC Socket
