ATEN Secure KVM User Manual
32
Switches
Port 2 x Pushbuttons 4 x Pushbuttons 8 x Pushbuttons
Reset 1 x Semi-recessed Pushbutton
Power 1 x Rocker
LEDs
On Line / Selected 2 (Orange) 4 (Orange) 8 (Orange)
CAC activated 2 (Green) 4 (Green) 8 (Green)
Power 1 (Blue)
Key Lock LED 3 (Green; Num Lock, Caps Lock, Scroll Lock)
Video 1 (Green, on back panel)
Emulation Keyboard/Mouse USB
Video
3840 x 2160 @ 30 Hz*; DVI Dual Link: 2560 x 1600; DVI
Single Link: 1920 x 1200; DVI-A: 2048 x 1536
Scan Interval N/A
I/P Rating 100–240V~ ; 50-60 Hz; 1A
Environment
Operating Temp. 0–50°C
Storage Temp. -20–60°C
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 1.78kg 1.79kg 3.05kg
Dimensions (L x W x H)
335 x 164 x 44
mm
335 x 164 x 44
mm
432 x 205 x 66
mm
* DVI Secure KVM Switches offer 3840 x 2160 @ 30 Hz video output on compatible HDMI-interfaced
monitors/computers with ATEN DVI-to-HDMI KVM cables
ATEN DVI Dual Display Secure KVM
Function CS1142D CS1144D CS1148D
Computer
Connections
Direct 2 4 8
Max. 2 4 8
Console Connections 1 Direct
Port Selection Pushbutton
Connectors
Console
Ports
Keyboard
1 x 6-pin Mini-DIN Female (Purple)
1 x USB Type A Female (2/4-Port Black; 8-Port White)
Video 2 x DVI-I Dual Link Female (White)
Mouse
1 x 6-pin Mini-DIN Female (Green)
1 x
USB Type A Female (2/4-Port Black; 8-Port White)
