ATEN Secure KVM User Manual
33
Speaker 1 x Mini Stereo Jack Female (Green)
Microphone
N/A
CAC 1 x USB Type A Female (Black)
KVM Ports
Keyboard/
Mouse
2 x USB Type-B
Female (White)
4 x USB Type-B
Female (White)
8 x USB Type-B
Female (White)
Video
4 x DVI-I Dual Link
Female (White)
8 x DVI-I Dual Link
Female (White)
16 x DVI-I Dual
Link Female
(White)
CAC
2 x USB Type-B
Female (White)
4 x USB Type-B
Female (White)
8 x USB Type-B
Female (White)
Speaker
2 x Mini Stereo
Jack Female
(Green)
4 x Mini Stereo
Jack Female
(Green)
8 x Mini Stereo
Jack Female
(Green)
Microphone
N/A
Power 1 x 3-prong AC Socket
Switches
Port 2 x Pushbuttons 4 x Pushbuttons 8 x Pushbuttons
Reset 1 x Semi-recessed Pushbutton
Power 1 x Rocker
LEDs
On Line / Selected 2 (Orange) 4 (Orange) 8 (Orange)
CAC activated 2 (Green) 4 (Green) 8 (Green)
Power 1 (Blue)
Key Lock LED 3 (Green; Num Lock, Caps Lock, Scroll Lock)
Console Video 2 (Green, on back panel)
Emulation Keyboard/Mouse USB
Video
3840 x 2160 @ 30 Hz*; DVI Dual Link: 2560 x 1600; DVI
Single Link: 1920 x 1200; DVI-A: 2048 x 1536
Scan Interval N/A
I/P Rating 100–240V~ ; 50-60 Hz; 1A
Environment
Operating Temp. 0–50°C
Storage Temp. -20–60°C
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 2.12kg 2.13kg 3.35kg
Dimensions (L x W x H)
335 x 164 x 66
mm
335 x 164 x 66
mm
432 x 205 x 66
mm
* DVI Secure KVM Switches offer 3840 x 2160 @ 30 Hz video output on compatible HDMI-interfaced
monitors/computers with ATEN DVI-to-HDMI KVM cables
