3.3 Video Extender Information
(VM7514 / VM8514 only)
Video extender information contains the extender type, interface count, and model name of each video
extender.
API
/api/v1.0/system/videoExts
/api/v1.0/system/videoExts/<id>
Request
GET: get information of all video extenders or a single video extender specified.
Response
Success
200 OK
1. For all video extenders:
Field
Type
Value
Description
maxTxCount
number
{maximum Tx video
extender count}
Maximum number of Tx video extenders
supported.
maxRxCount
number
{maximum Rx video
extender count}
Maximum number of Rx video extenders
supported.
videoExts
array (object)
Container of all video extender information.
id
string
{video extender ID}
Video extender ID.
type
string
{video extender type }
Video extender type.
idx
number
{video extender index}
Video extender index.
modelName
string
{model name}
Model name.
interfaceCount
number
{interface count}
Number of Interface supported.
fwVersion
string
{FW version}
Firmware version.
2. For a single video extender:
Field
Type
Value
Description
id
string
{video extender ID}
Video extender ID.
type
string
{video extender type }
Video extender type.
idx
number
{video extender index}
Video extender index.
modelName
string
{model name}
Model name.
interfaceCount
number
{interface count}
Number of Interfaces supported.
fwVersion
string
{FW version}
Firmware version.
