Aten VM6404HB [16/32] Device configuration
![Aten VM6404HB [16/32] Device configuration](/views2/1977706/page16/bg10.png)
16
All information, documentation and specifications contained in this media are subject to change without prior notice by the manufacturer. Please
visit our website to find the most up-to-date version.
6 Video
ATEN devices provide APIs for configuring their video-related settings, including video configuration, video
input/output ports, video connection, and etc.
6.1 Device Configuration
Contains all video configurations of the ATEN device.
API
/api/v1.0/video/configs
Request
GET: get device’s video configurations.
PATCH: modify device’s video configurations.
Field
Type
Value
Description
edid
object
EDID mode.
value
number
1
Use ATEN’s default EDID.
2
Use EDID of the 1
st
video output port.
3
Use remixed EDID.
osd
object
OSD setting.
value
number
1
Turn OSD off.
2
Turn OSD on.
blank
object
Blank screen setting.
value
number
1
Turn blank screen off.
2
Turn blank screen on.
Response
Success
200 OK
Field
Type
Value
Description
scaler
number
0
Support scaling.
1
Scaling unsupported.
edid
object
EDID mode.
valid
array (number)
Indicates the EDID modes supported.
value
number
0
EDID unsupported.
1
Use ATEN’s default EDID.
2
Use EDID of the 1
st
video output port.
3
Use remixed EDID.
osd
object
OSD setting.
valid
array (number)
Indicates the OSD settings supported.
value
number
0
OSD unsupported.
1
Turn OSD off.
2
Turn OSD on.
blank
object
Blank screen setting.
valid
array (number)
Indicates the black screen settings supported.
value
number
0
Blank screen unsupported.
1
Turn blank screen off.
2
Turn blank screen on.
