3.2 Video Board Information
(VM1600A / VM3200 / VM3250 only)
Video board information contains the board type, interface count, and model name of each video board.
If video extenders are attached, the related information is included as well. Note that video board
information is only supported by video modular products.
API
/api/v1.0/system/videoBoards
/api/v1.0/system/videoBoards/<id>
Request
GET: get information of all video boards or a single video board specified.
Response
Success
200 OK
1. For all video boards:
Field
Type
Value
Description
maxInputCount
number
{maximum input video
board count}
Maximum number of input video boards
supported.
maxOutputCount
number
{maximum output video
board count}
Maximum number of output video boards
supported.
videoBoards
array (object)
Container of all video board information.
id
string
{video board ID}
Video board ID.
type
string
{video board type }
Video board type.
idx
number
{video board index}
Video board index.
modelName
string
{model name}
Model name.
interfaceCount
number
{interface count}
Number of Interfaces supported.
fwVersion
string
{FW version}
Firmware version.
videoExts
object
Video extender information, if attached
(see 3.3 Video Extender Information).
2. For a single video board:
Field
Type
Value
Description
id
string
{video board ID}
Video board ID.
type
string
{video board type }
Video board type.
idx
number
{video board index}
Video board index.
modelName
string
{model name}
Model name.
interfaceCount
number
{interface count}
Number of Interfaces supported.
fwVersion
string
{FW version}
Firmware version.
videoExts
object
Video extender information, if attached
(see 3.3 Video Extender Information).
