Digital angle finder 0580

INTRODUCTION

• This measuring tool is intended for digitally measuring

and deﬁ ning angles from 0° to 220° (horizontal and

vertical)

• Read this instruction manual carefully before use and

save it for future reference 2

TECHNICAL SPECIFICATIONS

Material aluminium

Measuring range 0° - 220°

Measuring accuracy

- angle +/- 0.5°

- bubble level 1 mm/m

Lowest indication unit 0.1°

Power supply 1x 6LR61/9V battery

Estimated battery life 20 hours

Operating temperature -10°C to 50°C

Storage temperature -20ºC to 70°C

Automatic switch-off after approx. 5 min. of inactivity

Length 380 mm

Weight 0,18 kg

TOOL ELEMENTS 1

A On/off button

B “HOLD” button for retaining measured values

C LCD display

D Bubble level for horizontal planes

E Bubble level for vertical planes

F Base leg

G Fold-out leg with 32 cm ruler

H Battery compartment cover

J Low battery level indicator

K Retain mode (“HOLD”) indicator

USE

• Mounting of battery 3

- use exclusively alkaline-manganese or rechargeable

batteries

- remove cover H

- insert 9V battery (pay attention to correct

polarisation)

- mount cover H

- when battery level is low, symbol J 1 will appear in

display

- when symbol J 1 appears in the display for the ﬁ rst

time, measuring is still possible but with reduced

accuracy; replace the battery

- always remove the battery from the tool, if the tool

will not be used for a long period

• On/off

- switch on/off the tool by pressing “On/Off” button A 1

- after approximately 5 minutes without button

actuation or angle change, the measuring tool

automatically switches off to preserve battery life

• Measuring angles 4

! protect the measuring tool against impact and

shock (dropping or banging the tool may lead to

faulty measurements)

! keep the contact edges of the measuring tool

clean (debris particles may lead to faulty

measurements)

- position base leg F 1 and fold-out leg G 1 against

the edges to be measured

- the reading in display C 1 corresponds with angle X

and remains unchanged until the legs are moved

! when directly projecting a measured angle onto a

workpiece, pay attention that base leg F and fold-

out leg G are not moved and that the retaining

(“HOLD”) mode is not switched on

• Retaining measured values

- the current reading can be retained in display C 1 by

pressing “HOLD” button B 1 (symbol K 1 will

appear in display)

- the reading remains unchanged (even when the legs

are moved) until “HOLD” button B is pressed again

! be aware that the retaining mode also

automatically switches off after 5 minutes of

inactivity

APPLICATION ADVICE

• Use “HOLD” button B 1 for deﬁ ning angles at hard-to-

reach and/or dark places where measuring and reading

cannot take place simultaneously

• Use bubble level D 1 or E 1 for deﬁ ning angles when

only one reference point is available 5

GUARANTEE / ENVIRONMENT

• Always keep the measuring tool free of dust, moisture

and direct sunlight

• Clean the tool with a dry, soft cloth (do not use cleaning

agents or solvents)

• Always store the tool indoors in its protective carton/

case

• Do not disassemble or modify the tool in any way

• This SKIL product is guaranteed in accordance with

statutory/country-speciﬁ c regulations; damage due to

normal wear and tear, overload or improper handling will

be excluded from the guarantee

• In case of a complaint, send the tool undismantled

together with proof of purchase to your dealer or the

nearest SKIL service-station (addresses are listed on

www.skileurope.com)
