Aten SN3401P [21/111] Hardware setup

Chapter 2

Hardware Setup

Before you Begin

Placement Options

For flexibility and convenience, Secure Device Server can be mounted onto a

wall or DIN rail, as described below.

Wall Mount

To wall mount the Secure Device Server, doe the following:

Using 4 self-supplied screws, users can mount the unit onto a wall via the screw

holes at its sides, as shown below.

1. Important safety information regarding the placement of this

device is provided on page 87. Please review it before

proceeding.

2. Make sure the power of all devices to be connected have been

turned off.
