Aten SN3401P [51/111] General settings

Chapter 4. Web Console

General Settings

The General Settings contains 2 tabs: General and Time.

General

Item Description

Device name Sets the device name for the Secure Device Server.

Description Enter a description for the device if needed.

MFG Displays the MFG (Manufacturing Number) of the device.

Note: The Manufacturing Number is an internal serial number

used by ATEN’s factory and technical support staff to identify

products.

MAC Displays the MAC address of the Secure Device Server.

Uptime Displays the amount of time the device has been running for.

Power source Displays the device’s current power source.
