Aten SN3401P [29/111] Serial port pin assignments

Chapter 2. Hardware Setup

Serial Port Pin Assignments

The pin assignments of Secure Device Server’s serial ports are provided below:

Configuration

RS-232

RS-422

RS-485 (4 wires)

RS-485 (2 wires)

1 DCD RxD - (A) -

2 RxD RxD + (B) -

3 TxD TxD + (B) Data + (B)

4 DTR TxD - (A) Data - (A)

5 GND GND GND

6 DSR - -

7 RTS - -

8 CTS - -

9 - - -
