Lifan LF 620 [11/88] Unlock pull the button backwards
![Lifan LF 620 [11/88] Unlock pull the button backwards](/views2/1986630/page11/bgb.png)
620
620
19
Door
Lock and Unlock
Insert and turn the key in the key hole.
Unlock: Turn the key clockwise.
Loc k: Tur n the key cou nt ercl ock wise.
The other doors can be lo cked and unlocked
together with the door at the driver sid e
when the is install ed.central door lo cking
Lockin g Butt on of Inte rnal Door Handle
Move the locking button.
Unlock: Pull the button backwa rds.
Lock: Push the button forwards.
Set the button in lo ckin g posit ion if need to
clo se the door outsid e. Pull the handle
outwards fir st if need to clo se the front doors
at le ft and rig ht sid e.
Central Door Locking Switch at Driver Side
The door at the driver side can be opened
in the vehicle even if the locking button of
the internal handle is placed at the locking
position.
The door at the driver side can not be locked
if it is unclosed and the ignition key is left in
the ignition switch.
20
Press the switch.
Automatic Lock and Unlock (Optional)of Door
Child Protection Lock (Rear Door)
Move the lock bar to position “LOCK”,
as shown in the figure .
The rear door ca n not be opened by the
interna l handle if it is lock ed by the ch ild
protecti on lock . Apply this protecti on
lock at any time with child in yo ur ca r.
Warning
Ensure all the doors are locked before driving, especially
with child in your car. Correctly using safety belt and
locking the doors can protect you from serious injury
when crash occurs and prevent the doors opening
accidentally.
A. Automatic Lock (20 Km/h))
When vehicle speed exceeds 20Km/h, all doors
will be lo cked automatic all y, while decele rating
to belo w 20km/h and then acceleratin g to
above 20km/h, the doors will not be lo cked
again . However, after a stop of the vehic le
wit h engin e on, then clo se the door and continue
to driv e, when the speed exceeds 20km/h, the
doors will be lo cked again. The lo ck can be
automatic ally rele ased when the ig nit io n swit ch
is disconnected.
B. Oil-cut and Unlock in Crash
The oil sup pl y at the BC M
oil con trol end and the lock will be rel eas ed
aut om at ical ly for three times when crash
occ ur s.
will be cut off
。
Lock: Press to lock all the doors
simultaneously.
“ ”
Unlock : Press for the first time to
open the left front door and
“ ”
the sec ond time
to open the rest three door s si mul taneo usl y.
