Vehicle Identification
Vehicle Identification Number (VIN)
VIN is located within the engine compartment
as well as at the upper left side of dash board
(as shown at “1” in the above figure), which
is used for the record by the owner. Manufacturer
data plate with VIN is located within the engine
compartment (as shown at “2” in the above
figure).
Engine No.
6
The engine No. is located on the cylinder
block (as shown in the above figure) .
Product Model
LF7162 LF7162A LF7162B LF7162C LF7162D LF7162E
Maximum Speed (km/h)
≥180
Engine Model
Tritec1.6 LF481Q3
Type 4-cylinder in-line, 16 valves, single OHC, MFI
Displacement (ml)
1596 1587
Maximum Power (kw)
85（6000r/min) 78（6000r/min)
Maximum Torque (N·m)
149(4500r/min) 137(4500r/min)
Idle Speed (r/min)
800±50
Oil Consumption (L/100 ㎞)
7.5 7.8
Grade Ability (%)
≥30
Emission Standard GB III/GB IV GB III/GB IV
2
1
1
LF4 81Q3
TRI TEC1. 6L
Instru ction Manual of Lifan Sedan
LIFAN
Instru ction Manual of Lifan Sedan
Instru ction Manual of Lifan Sedan
LIFAN
620 620
Chongqing Lifan Passenger Vehicle Co., Ltd.
Chongqing Lifan Passenger Vehicle Co., Ltd.
